Locinox Gate Closers

The Locinox Commercial Hydraulic Gate Closer, also known as the Samson 2, is a high-quality gate closer designed for commercial and heavy-duty applications. This hydraulic gate closer offers reliable and controlled gate closure, ensuring security and convenience for your property.

Built with durability in mind, the Samson 2 Gate Closer is constructed from robust materials that can withstand heavy use and harsh weather conditions. It is suitable for various gate types, including metal gates, wooden gates, and PVC gates.

The gate closer features adjustable closing speed and force, allowing you to fine-tune the closing action to meet your specific requirements. It also includes a hydraulic damping system for smooth and controlled gate closure, preventing slamming or sudden movements.

Installation is made easy with the included mounting brackets and comprehensive instructions. The Samson 2 Gate Closer is designed for horizontal or vertical installation, offering flexibility to accommodate different gate configurations.

With its commercial-grade performance and reliability, the Locinox Commercial Hydraulic Gate Closer is an excellent choice for commercial properties, industrial facilities, and high-traffic areas.

Hold gates up to 2m and 150kg

Specifications

• Opening angle up to 150° depending on the situation
• Specially developed for outdoor use: industrial quality
• Scratch resistant and corrosion free anodized aluminium housing
• Closing speed unaffected by temperature changes
• Fast and easy fixing with Quick-Fix
• For left and right turning gates
• Easy to open: Max. 25 Nm

Installation Manual

Videos

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.

WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app

Specifications:

• Motorised gate closer with integrated electronics
• 150 Nm torque
• Fits on 80 mm profiles
• For pedestrian gates up to 1400 mm wide and 100 kg
• Steel gear box
• Anodized aluminium cover
• 3 different arm options for installation
• Easy mounting with Quick-Fix

• Compact and vandal-proof design
• Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
• Motor voltage: 24V DC
• Integrated warning light
• Automated obstacle detection with reverse function
• Brushless motor: long lifespan and intensive usage
• Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

• Specifically developed for outdoor use.
• Weatherproof and dustproof.
• IP55 rated.
• Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
• 2 year manufacturer’s warranty.
• Tested on 500,000 movements.

INSTALLATION

• For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
• Suitable for both left and right turning gates.
• Requires a strike to determine the zero position.
• No safety sensors required thanks to the standard low energy mode.
• 3D installation video is available in an app.
• 3 configurable inputs for connecting access control, security sensors, etc.
• 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

• Programming via an app
• Step-by-step guide with video instructions available within the app
• App is available for ANDROID and IOS

MATERIAL

• Anodised aluminium housing.
• Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
• UV-resistant and colour-fast.

VIDEOS
