CPPS313
Plastic square cap 30x30mm (1-2.5mm wall thickness) White

The plastic square cap is designed for 30x30mm square tubes with a wall thickness of 1-2.5mm. It serves as a protective cover for the ends of the tubes, providing a clean and finished look. Made from high-quality plastic, this square cap offers durability and reliable performance. It is easy to install and ensures a secure fit, preventing dust, debris, and moisture from entering the tube. Whether for industrial applications, commercial projects, or DIY crafts, this plastic square cap is a versatile solution for protecting and enhancing your square tube assemblies.

$ 1.80 1.8 AUD
GMSG711
Beninca BULL1224 Turbo 24V 1200kg Complete Kit x 3 remotes

Beninca BULL1224 Turbo 24V 1200kg - Motor Only with 2 remotes

Max Speed: 24m/min

$ 1,699.00 $ 1,575.00 1575.0 AUD
FK281
Swing Gate Handle Square Plate OFFSET D HANDLE

Swing Gate Handle Square Plate OFFSET D HANDLE

Offset Fixed "D" Handle Kit - suits 60mm Mortice Lock.

Kit Components

  • 1 x LOCKTON Art. D-OFFSET-SC - Offset Fixed "D" Handle
  • 1 x LOCKTON Art. SQ-05V-SCP - Square End Furniture Plain Plate

PRODUCT SPECIFICATION

Plate Specifications

  • Material: Solid Brass
  • Dimensions (L x W x D): 165 x 46 x 18mm
  • Mounting Screw Spacing: 150mm

Handle Specifications

  • Material: Solid Brass
  • Handing: Non-Handed
  • 10 Year Warranty (*)
  • Clearance: 44mm (from rear of handle to door)
  • Handle Diameter: 16mm
  • Mounting Screw Spacing: 150mm
  • Screw Thread: M5
  • Supplied with 2 x Mounting Screws


$ 128.50 128.5 AUD
FK277
Stainless Steel 304 Swing / Sliding Gates Pull Handle Black 120x40mm

Stainless Steel 304 Swing / Sliding Gates Pull Handle

  • Material: 304 Stainless steel
  • Color: Black finished
  • Size: 102x51mm
  • Recessed size: 83x38x10mm
  • Accessories: Screws




$ 12.45 12.450000000000001 AUD
FK279
Stainless Steel 304 Swing / Sliding Gates Pull Handle 120x40mm

Stainless Steel 304 Swing / Sliding Gates Pull Handle

  • Material: 304 Stainless steel
  • Color: Stainless steel finished
  • Size: 120x40mm
  • Recessed size:  95x31x10mm
  • Accessories: Screws




$ 12.45 12.450000000000001 AUD
ET138
Centsys G-Ultra 4G GSM

G-ULTRA – The ultimate GSM solution

With the G-ULTRA, your entire world fits into the palm of your hand, giving you complete control at your fingertips. This is the evolution of GSM technology, designed to offer you the ultimate flexible, mobile-based access control and monitoring solution and allowing you to transcend archaic notions of what GSM can achieve.

Unbridled. Unchained. Unmatched. Ultra.

Main features:

  • Monitor up to four electrical devices by receiving push notifications
  • Use the outputs to control up to six devices from your phone (two additional onboard relays)
  • Intelligent monitoring of CENTSYS gate motors’ status outputs (for example gate opening, gate left open, etc.)
  • Suitable for a wide variety of access automation applications
  • Time-barring and visitor control – ideal for B & Bs and guesthouses
  • LCD screen for easy access to diagnostics
  • Instant activation via G-REMOTE mobile app
  • Easy setup via G-WEB PLUS online interface

Devices that can be monitored via the inputs

  • House alarm: activated
  • Electric fence: alarm triggered
  • Geyser status: On/Off
  • Mains power: On/Off
  • Fridge aboard your boat: On/Off
  • Borehole pump status: Running/Off
  • Water reservoir: Full/Empty
  • Entrance gate status: Open/Pedestrian

 Devices that can be controlled via the outputs

  • Automated entrance gates
  • Geysers
  • Appliances, e.g. the fridge aboard your boat
  • Air conditioners
  • Borehole pumps
  • Lighting systems
  • Irrigation and water features
  • Alarm systems




$ 585.00 585.0 AUD
WH603
Overhead Sliding Gate/Hanging Barn Door 2 Nylon Wheel for Gate up to 120kg

Overhead Sliding Gate/Hanging Barn Door 2 Nylon Wheel for Gate up to 120kg

$ 39.50 39.5 AUD
ETKP001
Waterproof Fingerprint Video Intercom Access

Intercom

> 2.4G WiFi connection
> Android and iOS available
> Full duplex voice intercom
> 2MP+wide angle camera and night vision
> Support TF card with unlimited capacity
> Support motion detection, playback, take picture/video, unlock remotely



Access Control

> Touch key with one relay, 1000 users (988 common+2 panic+10 visitor)
> PIN Length: 4~6 digits
> EM card, Mifare card optional
> Wiegand 26~44 bits in put & output
> Can be used as Wiegand reader with LED & buzzer
> User data can be transferred
> 2 devices can be interlocked for 2 doors

Video Intercom
Network2.4G WiFi connection
Pixel2.0Mpx (1080P)
Visual AngleHorizontal   140° wide angle
Night VisionIR-CUT (Colorful at daytime, black and white at   night)
Extended MemoryTF card with unlimited capacity
IntercomFull duplex voice intercom
Other FunctionsMotion detection; Playback; Take picture/video; Unlock remotely

Access Control
User Capacity1000(100 fingerprints + 900 card&PINs)
Common User988
Visitor User10
Panic User 2
PIN Length4~6 digits
Proximity Card ReaderEM or Mifare
Radio Technlogy125KHz/13.56MHz
Read Range 2~6cm
Wiring ConnectionsRelay output, exit button, alarm, door contact, Wiegand input/output
RelayOne (NO, NC, Common)
Adjustable Relay Output Time0~99 Seconds (5 seconds default)
Lock Output Load2 Amp Maximum
Wiegand   Interface  EM card version: Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits)
Mifare card version:Wiegand 26~44 bits input & output (Factory default: Wiegand 34bits)
PIN Output4 bits,8bits (asc11),10 digits Virtual Number(Factory default:4bits)

Electric
Operating VoltageDC 12V
Idle Current≤ 150mA
Active Current≤ 250mA


$ 169.00 169.0 AUD
GM195
Battery Backup For Beninca Motor 1.3Ah 12VDC for Bull 424 SW & 624 SW

Battery backup For Beninca Motor 1.3Ah 12VDC

Compatible with Bull 424 SW & Bull 624 SW



Tigerlink Hardware
PH: 03 99578942



$ 185.00 185.0 AUD
ETML001
Wired Surface-Mounted NC Magnetic Lock Contact Sensor
$ 59.00 59.0 AUD
MS827
Aluminium Fence Spear: Heritage Female to fit inside 16mm Round Tube

The Aluminium Spear Top Picket Top Female is a stylish and functional accessory designed to elevate the look of your fencing system. Crafted from high-quality aluminum, this picket top adds a touch of elegance and sophistication to your outdoor space. It is specifically designed for 16mm round tubes, ensuring a seamless fit and easy installation. The Aluminium Spear Top Picket Top Female not only enhances the aesthetics of your fence but also provides reliable security. Perfect for both residential and commercial applications, it combines style and functionality in one.

Measurement: 120(H)x75(W)mm

MS815 Optional for 19mm tube available.

$ 4.95 4.95 AUD
MOT115
Beninca Underground Single Swing Gate Motor DU.IT24NVE Single KIT



Technical Data Sheet



Power supply: 240 Vac (50-60Hz)

Motor supply: 24 Vdc

Max absorbed current: 11 A

Torque: 280 Nm

Opening time: 15”

Duty cycle: intensive use

Protection level: IP67

Operating temperature: -20°C /+50°C

Leaf max dimension: 3.5 m

Weight: 10 kg

DU.ITIX weight: 8.1 kg

DU.ITCF weight: 9.6 kg

$ 2,155.00 2155.0 AUD
MOT116
Beninca Underground Double Swing Gate Motor DU.IT 24NVE Double KIT

Beninca Underground Double Swing Gate Motor DU.IT 24NVE Double KIT

Electromechanical underground operator

Product Details:

  • Irreversible 24 Vdc electromechanical geared motor for intensive use
  • The encoder device ensures maximum safety and precision in the gate moving phases
  • Amperometric sensor obstacle detection system to prevent crushing
  • Optional battery-powered operation
  • Full metal mechanics and built-in mechanical stop.
  • Suitable for gate leafs up to 3.5m
Built in Physical Stops

Yes

Motor Supply

24Vdc

Motor Type

Electromechanical

Max Gate Weight

300Kg

Duty Cycle

99%

Encoder

Yes

Wind Resistance

Light breeze

Gate Usage

Residential

Opening Time (Secs)

15 seconds

Choose kit option

Motor Only, Single Kit, Pair Kit

Donwload installation DU.IT 24NVE

$ 3,855.00 3855.0 AUD
HN133
Butt Hinges Stainless steel Fixed pin 100x70x2.5mm/ 2 hinges Black

The Butt Hinges are a set of two stainless steel hinges with a fixed pin design. Measuring 100x70x2.5mm, these hinges provide reliable support and smooth operation for doors, cabinets, and other applications. Made from high-quality stainless steel, they offer excellent durability and resistance to rust and corrosion. The fixed pin ensures stability and security, making them suitable for both residential and commercial use. Whether you're working on a renovation project or building new furniture, the Butt Hinges deliver reliable performance and long-lasting functionality.

$ 18.95 18.95 AUD
GCHC100
Locinox VENUS Motorised Gate Closer with Sliding Arm for Pesdestrian Swing Gates - Black

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual

$ 1,864.00 1864.0 AUD
GCHC101
Locinox VENUS Motorised Gate Closer with Sliding Arm for Pesdestrian Swing Gates - Silver

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual


$ 1,864.00 1864.0 AUD
GCHC102
Locinox VENUS Motorised Gate Closer with Articulated Arm for Pesdestrian Swing Gates - Black

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual


$ 1,864.00 1864.0 AUD
GCHC103
Locinox VENUS Motorised Gate Closer with Articulated Arm for Pesdestrian Swing Gates - Silver

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual



$ 1,864.00 1864.0 AUD
GCHC104
Locinox VENUS Motorised Gate Closer with Compact Arm for Pesdestrian Swing Gates with 180° Hinges - Black

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual



$ 1,864.00 1864.0 AUD
GCHC105
Locinox VENUS Motorised Gate Closer with Compact Arm for Pesdestrian Swing Gates with 180° Hinges - Silver

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.


WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app



Specifications:

  • Motorised gate closer with integrated electronics
  • 150 Nm torque
  • Fits on 80 mm profiles
  • For pedestrian gates up to 1400 mm wide and 100 kg
  • Steel gear box
  • Anodized aluminium cover
  • 3 different arm options for installation
  • Easy mounting with Quick-Fix
  • Compact and vandal-proof design
  • Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
  • Motor voltage: 24V DC
  • Integrated warning light
  • Automated obstacle detection with reverse function
  • Brushless motor: long lifespan and intensive usage
  • Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

  • Specifically developed for outdoor use.
  • Weatherproof and dustproof.
  • IP55 rated.
  • Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
  • 2 year manufacturer’s warranty.
  • Tested on 500,000 movements.

INSTALLATION

  • For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
  • Suitable for both left and right turning gates.
  • Requires a strike to determine the zero position.
  • No safety sensors required thanks to the standard low energy mode.
  • 3D installation video is available in an app.
  • 3 configurable inputs for connecting access control, security sensors, etc.
  • 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

  • Programming via an app
  • Step-by-step guide with video instructions available within the app
  • App is available for ANDROID and IOS

MATERIAL

  • Anodised aluminium housing.
  • Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
  • UV-resistant and colour-fast.

VIDEOS




DOCUMENTS


Installation Manual



$ 1,864.00 1864.0 AUD
