The MITTO COOL BFT Remote is a versatile 4-button remote control designed for BFT gate systems. With its seamless compatibility, this remote allows you to conveniently operate your gate with ease. The 4-button design provides intuitive control, allowing you to perform various gate functions effortlessly. With its reliable signal transmission, the GM845 ensures accurate and responsive commands, ensuring smooth and efficient gate control. This remote control is built with high-quality materials for durability and long-lasting performance. Upgrade your BFT gate system with the GM845 BFT Remote and enjoy convenient and reliable wireless control.

Colour: Dark Blue

• Operating frequency 433Mhz
• 12V power supply
• Range up to 150 meters
• Model: D112318
• Number of channels: 4
• Code type: variable
• Operating frequency: 433.92 MHz

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.

WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app

Specifications:

• Motorised gate closer with integrated electronics
• 150 Nm torque
• Fits on 80 mm profiles
• For pedestrian gates up to 1400 mm wide and 100 kg
• Steel gear box
• Anodized aluminium cover
• 3 different arm options for installation
• Easy mounting with Quick-Fix

• Compact and vandal-proof design
• Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
• Motor voltage: 24V DC
• Integrated warning light
• Automated obstacle detection with reverse function
• Brushless motor: long lifespan and intensive usage
• Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

• Specifically developed for outdoor use.
• Weatherproof and dustproof.
• IP55 rated.
• Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
• 2 year manufacturer’s warranty.
• Tested on 500,000 movements.

INSTALLATION

• For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
• Suitable for both left and right turning gates.
• Requires a strike to determine the zero position.
• No safety sensors required thanks to the standard low energy mode.
• 3D installation video is available in an app.
• 3 configurable inputs for connecting access control, security sensors, etc.
• 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

• Programming via an app
• Step-by-step guide with video instructions available within the app
• App is available for ANDROID and IOS

MATERIAL

• Anodised aluminium housing.
• Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
• UV-resistant and colour-fast.

VIDEOS

DOCUMENTS

Installation Manual

VENUS is a plug-and-play motorised gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor’s performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

The VENUS motorised gate closer is specifically designed for pedestrian gates up to 1400 mm and 100 kg.

VENUS is a brushless motor specially designed for semi-manual or fully automated outdoor use.

WHAT MAKES IT SPECIAL?

• Safe, reliable operation thanks to low-energy speed control and integrated obstacle detection.

• All-in-one gate operator with integrated power supply and circuit board, input/output connectors and indicator light.

• Easy setup with free mobile app

Specifications:

• Motorised gate closer with integrated electronics
• 150 Nm torque
• Fits on 80 mm profiles
• For pedestrian gates up to 1400 mm wide and 100 kg
• Steel gear box
• Anodized aluminium cover
• 3 different arm options for installation
• Easy mounting with Quick-Fix

• Compact and vandal-proof design
• Input main Power supply: 115V AC ±10% (60Hz) to 230V AC ±10% (50Hz), Max 5A
• Motor voltage: 24V DC
• Integrated warning light
• Automated obstacle detection with reverse function
• Brushless motor: long lifespan and intensive usage
• Reversible motor with backdrivability for easy manual use – to be combined with a lock

PERFORMANCE

• Specifically developed for outdoor use.
• Weatherproof and dustproof.
• IP55 rated.
• Maintenance-free (no need to lubricate or add oil). Always verify if there are specific safety regulations by local authorities.
• 2 year manufacturer’s warranty.
• Tested on 500,000 movements.

INSTALLATION

• For gate profiles of at least 80 mm, with a material thickness of at least 2 mm steel
• Suitable for both left and right turning gates.
• Requires a strike to determine the zero position.
• No safety sensors required thanks to the standard low energy mode.
• 3D installation video is available in an app.
• 3 configurable inputs for connecting access control, security sensors, etc.
• 3 configurable outputs for connecting an electric strike, electromagnetic strike plate, warning lamp or ambient lamp and a fixed 24V DC power supply.

CONFIGURATION

• Programming via an app
• Step-by-step guide with video instructions available within the app
• App is available for ANDROID and IOS

MATERIAL

• Anodised aluminium housing.
• Corrosion resistance of 500 hours in salt spray test, according to ISO9227.
• UV-resistant and colour-fast.

VIDEOS

DOCUMENTS

Installation Manual
