The WH395 Sliding Gate Wheel is a high-quality and durable solution for smooth and efficient movement of your sliding gate. With its U-groove design and 100mm internal diameter, this wheel provides excellent stability and support. The double-bearing system ensures smooth and silent operation, minimizing friction and wear. Upgrade your gate system with the WH395 Sliding Gate Wheel for reliable performance and enhanced convenience.

Hold weight up to 350kg

Installing a sliding gate wheel involves a few key steps to ensure the gate operates smoothly. Here’s a step-by-step guide to help you install it:

Materials Needed:

• Sliding gate wheel
• Measuring tape
• Cutting machine
• Drill and drill bits
• Screws and bolts
• Wrench or screwdriver

Steps for Installation:

Prepare the Gate and Track:

• Before installing the wheels, ensure that your sliding gate is already installed and that the sliding track is properly laid out.
• The track should be level and secure to ensure smooth operation.

Step One:
Measure the sliding gate wheel cradle, ensuring there's enough space to attach the wheel to the steel frame. Use a cutting wheel to make the cut, but first, drill four holes (one in each corner) using an 8-10mm drill bit. This will ensure the square hole is clean in each corner.

Step Two:
Clean up the rectangular hole with a file to ensure smooth edges, then spray the area with galvanized paint for protection.

Step Three:
Place the sliding gate wheel into the cut-out and check that it can rotate freely. Ensure there’s enough space for securing the wheel with a tek screw.

Step Four:
When screwing in the tek screws, make sure the wheel is aligned with the edge of the steel. The last thing you want is for the wheel to be out of alignment. Avoid welding the wheel if possible, as this can make replacement more difficult later on.

The WH398 Sliding Gate Wheel with U-Groove is the perfect solution for smooth and effortless sliding gate operation. With its 100mm external diameter and U-groove design, this wheel provides exceptional traction and stability. The double-bearing system ensures optimal load-bearing capacity and reduces friction, resulting in seamless gate movement. Crafted from high-quality materials, this wheel is built to withstand heavy-duty use and resist wear and tear. Upgrade your sliding gate system with the WH398 Sliding Gate Wheel for reliable performance and durability.

Hold weights up to 350kg

Installing a sliding gate wheel involves a few key steps to ensure the gate operates smoothly. Here’s a step-by-step guide to help you install it:

Materials Needed:

• Sliding gate wheel
• Measuring tape
• Drill and drill bits
• Screws and bolts
• Wrench or screwdriver

Steps for Installation:

1. Prepare the Gate and Track:
   • Before installing the wheels, ensure that your sliding gate is already installed and that the sliding track is properly laid out.
   • The track should be level and secure to ensure smooth operation.
2. Determine the Wheel Placement:
   • Decide where the wheel brackets will go on the gate. Typically, the wheels should be placed at the bottom of the gate. Depending on the gate size.
   • The wheel’s placement is important for proper weight distribution and gate stability.
3. Mark the Drill Holes:
   • Hold the wheel brackets against the gate at the desired position.
   • Use a measuring tape to ensure the placement is even and at the correct height.
   • Mark the holes where the screws or bolts will go to secure the wheels.
4. Drill the Holes:
   • Drill holes at the marked points on the gate, making sure the holes are large enough for the screws or bolts provided in your wheel kit.
   • If you’re installing a single wheel, the hole placement should be centered along the gate's width.
5. Attach the Wheel Bracket:
   • Secure the wheel bracket to the gate using the screws or bolts.
   • Tighten them properly to ensure the bracket is secure. Be sure the wheel can rotate freely once attached.
6. Install the Wheel:
   • If the wheel is separate from the bracket, slide the wheel into its bracket or mounting system.
   • Tighten any screws or bolts holding the wheel in place, ensuring it rotates easily and is properly aligned.
7. Test the Gate:
   • Test the sliding gate by moving it along the track.
   • Check that the wheels glide smoothly without any obstruction or resistance. The gate should be stable and move freely.
8. Adjust if Necessary:
   • If the gate isn’t sliding smoothly, check the alignment of the wheels and track. You might need to adjust the wheel height or ensure that the track is level.
   • Make sure the wheels are aligned with the gate and track to avoid any friction.

Try not to weld them onto the sliding gate frame it will be a nightmare to replace them later

The WH405 Sliding Gate U-Groove Wheel with a 100mm diameter is a high-quality component designed for smooth and efficient operation of your sliding gate. With its U-groove design and Class A rating, this wheel offers excellent traction and durability. The wheel does not include a bracket, providing flexibility for mounting options. Upgrade your sliding gate system with the WH405 Sliding Gate U-Groove Wheel for reliable performance and long-lasting durability.

Hold weight up to 300kg

The Wh110 Sliding Gate Top Guide Roller is a heavy-duty accessory designed for sliding gates. With a size of 25x40mm, this top guide roller provides smooth and reliable guidance for your gate. It is made of durable nylon material, ensuring long-lasting performance. The Wh110 Guide Roller is designed for easy installation and is suitable for heavy gates. The black color adds a sleek and modern touch to your gate. Upgrade your sliding gate with this heavy-duty top guide roller for smooth and effortless operation.

The WH255 Sliding Gate Top Guide Holder with 2 Rollers is a versatile and reliable accessory for your sliding gate system. With a size of 200x162mm, this guide holder provides stable support and smooth operation. It comes with two rollers measuring 40x100mm, ensuring effortless gate movement and reducing friction. The durable construction and high-quality materials make it suitable for outdoor use. Upgrade your sliding gate with the WH255 Top Guide Holder for improved performance and reliability.

The WH288 Sliding Gate Top Guide Holder with 2 Rollers is a high-quality solution for your sliding gate system. With a size of 212x225mm and a maximum gate width of 75mm, this guide holder offers reliable support and smooth gate operation. It comes with two rollers measuring 40x60mm, ensuring optimal gate movement and reduced friction. The black finish adds a sleek and modern touch to your gate design. Upgrade your sliding gate with the WH288 Top Guide Holder for enhanced functionality and style.

The Wh312 Sliding Gate Post Top Guide Roller is an essential accessory for sliding gates. With a size of 25x40mm, this guide roller ensures smooth and reliable operation for your gate. It is made of high-quality materials for durability and longevity. The Wh312 Guide Roller is designed to be installed on gate posts, providing effective guidance and support. The white color adds a clean and stylish touch to your gate. Upgrade your sliding gate with this top guide roller for enhanced functionality and ease of use.

The SGSB411 Sliding Gate Holder Bracket is specifically designed for 65mm gates. It provides a secure and convenient solution for holding and guiding sliding gates. The sliding gate holder bracket features a welded cap for added strength and durability. With its sturdy construction and easy installation, the SGSB411 Sliding Gate Holder Bracket ensures smooth and reliable operation of your sliding gate system.

The SGSB412 Sliding Gate Holder Bracket is designed for 65mm gates and provides a reliable solution for holding and guiding sliding gates. It features a rubber stop for smooth and quiet operation, reducing noise and impact during gate movement. The sliding gate holder bracket is made with durable materials for long-lasting performance. With its easy installation and effective functionality, the SGSB412 Sliding Gate Holder Bracket ensures optimal performance of your sliding gate system.

The SGSB414 Sliding Gate Holder is specifically designed for 75mm gates, providing a reliable and secure solution for holding and guiding sliding gates. It features a rubber component that ensures smooth and quiet operation, reducing friction and wear on the gate. The sliding gate holder is easy to install and offers durability for long-term use. With its sturdy construction and functional design, the SGSB414 Sliding Gate Holder is an essential component for your sliding gate system.

The SGSB439 Sliding Gate Holder is specifically designed for 100mm gates, offering reliable and smooth operation for sliding gate systems. Featuring a welded cap, this gate holder provides added strength and durability, ensuring long-lasting performance. It is made from high-quality materials to withstand outdoor conditions and offers easy installation for convenient gate maintenance. Upgrade your sliding gate system with the SGSB439 Sliding Gate Holder for enhanced functionality and improved gate control.

The BK100 Sliding Gate End Stopper is a versatile solution designed for overhead sliding gates. It provides a secure stop point for the gate when fully opened, preventing it from going off track or causing any damage. With its multi-fit design, this end stopper is compatible with various sliding gate systems, offering flexibility in installation. Made with durable materials, it ensures long-lasting performance and reliable gate operation.

Upgrade the security of your gates with the FK125 Slide Pad Bolt available at TigerLink. This 190mm bolt offers a secure locking mechanism for your gates, providing peace of mind and enhanced protection. Our reliable gate hardware is designed to withstand various weather conditions and ensure long-lasting performance. Shop now and fortify your gates with the FK125 Slide Pad Bolt.
