Beninca Double Swing Gate Motor TOM5024E Motor Kit
The TOM series of motors is made by Italian company Beninca which translates into quality, reliability and performance. The TOM range uses linear shaft technology for added length and strength and 24 volt DC motors.
24 VOLT ELECTRIC GATE OPERATOR – RESIDENTIAL & COMMERCIAL –5.0 METRE LEAF
The powerful 24 volt swing gate electro mechanical operator. What makes TOM so special (and yes a little more expensive than most) is just below the top shaft cover. Easily accessible and adjustable mechanical stops. That along with ability to wire encoders makes the TOM highly adaptable to difficult sites where physical stops may be a problem to install. The TOM is a non reversible operator with key operated manual override but one of the main benefits of the 24 volt motor is the ability to use battery backup meaning you may never have to use the manual override key.
Reliable and innovative gear motor, thanks to the 2 adjustable mechanical stops in opening and closing accessible from above and positioned under the metal cover of the shaft. Ideal for the automation of any type of swing gate thanks also to the compact footprints (only 96 mm width) and screw-in brackets. The 45° inclination of the wiring cable allows the distance from the ground to be reduced to a minimum. The rear and front brackets, aligned on the same axis, enable the better distribution of loads by optimizing the lifespan of the actuator. The worm screw protected by wiper ring and stainless steel shaft make it suitable for dusty or sandy environments, or places with aggressive weather conditions
It is possible to use a variety of control boards to control the TOM but the factory designed board is the BRAINY which can be used as a one or two motor controller with a host of programmable parameters.
•At just 96 cm wide, the TOM telescopic linear motor for swing gates to 5 metres long.
•TOM features adjustable mechanical stops for opening and closing, patented FACE gears and a bronze release wheel with customised key.
•The 24 Vdc version, also guarantees standby power consumption of less than 0.8 W.
HIGH-QUALITY COMPONENTS The release wheel is made of bronze to maximise its life, reliability, and operation. The worm gear is protected by a wiper seal and a stainless-steel shaft, making it suitable for use in dusty, sandy or harsh environments.
COMPACT DESIGN Thanks to its compact dimensions, just 96 mm wide, TOM adapts to any situation. The 45° inclination of the cable also means that the operator can be installed flush with the floor.
EASY ACCESS TO MECHANICAL STOPS The adjustable stops at the top are accessible once the metal cover has been slid back. These stops slide on rails and can be easily fixed in the desired position using screws.
FASTENERS DESIGNED FOR MAXIMUM ADAPTABILITY The rear articulation, which can be fixed in three positions, reduces space requirements by adjusting for any misalignment of the panel during movement. The alignment of the front and rear brackets also ensures better load distribution by reducing bending, guaranteeing axial thrust and optimising operator life.
24 volts DC
0mA
5.5A
89W
1500Nm
19"
5000mm
80%
114mm
96mm
1575mm
9.4 Kg
IP44
Beninca Single Swing Gate Motor TOM5024E Motor Kit
Beninca Double Swing Gate Motor TOM3024E Motor Kit
24 VOLT ELECTRIC GATE OPERATOR – RESIDENTIAL & COMMERCIAL – 3.0 METRE LEAF
•At just 96 cm wide, the TOM telescopic linear motor for swing gates to 3 metres long.
1800Nm
9-21 seconds to 90 degrees
3000mm
132mm
88mm
796mm
8.2 Kg
Beninca Single Swing Gate Motor TOM3024E Motor Kit
BFT Solar Kit - Ecosol & Panel 40W
The ET802 Transformer for BFT Deimos A600/Virgo is a reliable and essential component designed for gate systems. This transformer is specifically designed for use with the BFT Deimos A600 and Virgo models, providing the necessary power supply for their operation. It ensures the proper functioning and performance of the gate system by converting the electrical input to the appropriate voltage required by the motor. The ET802 transformer offers a reliable and efficient power solution, allowing the gate system to operate smoothly. Upgrade your BFT Deimos A600 or Virgo gate system with the ET802 Transformer for reliable and consistent power supply.
The GM319 Swing Gate Replacement Control Board is specifically designed as a reliable replacement for Vect Centsys control boards in swing gate systems with a solar system. This control board ensures smooth operation and optimal performance of your swing gate, utilizing the power of solar energy. It offers seamless compatibility with Vect Centsys control boards, making installation and integration hassle-free. The GM319 control board comes with advanced features and functionalities, providing customization options to suit your specific requirements. With its durable construction and precise control capabilities, it delivers reliable performance and long-lasting operation. Upgrade your swing gate system with the GM319 Swing Gate Replacement Control Board for enhanced control and functionality, all powered by solar energy.
The Centsys Centurion Vantage 500 Single Swing Gate Motor Kit is designed for automating single swing gates with ease. This comprehensive kit includes a powerful motor, control electronics, and all necessary accessories for installation. Operating at 240V, it delivers reliable and efficient gate automation for single swing gates. With a maximum gate weight capacity of 500kg, this motor kit provides convenience and security for your property. The adjustable speed and force settings ensure smooth and safe gate operation. Upgrade your gate system with the Centurion Vantage 500 Single Swing Gate Motor Kit for enhanced convenience and peace of mind.
Max Weight : 750kgMax Width of Gate/Door: 4m
1 Centsys Vantage Motor Single Swing
3 Remotes
The Centsys Centurion Vantage 400 Single Swing Gate Motor Kit is a comprehensive solution for automating single swing gates. This kit includes a powerful motor, control electronics, and accessories necessary for installation. Designed for 240V operation, it provides reliable and smooth gate movement for single swing gates. With a maximum gate weight capacity of 500kg, this motor kit offers convenience and security. It features adjustable speed and force settings, ensuring optimal performance and safety. The Centurion Vantage 400 Single Swing Gate Motor Kit is a reliable choice for enhancing your gate automation system.
Max Weight : 500kgMax Width of Gate/Door: 2.5m
1 Centsys Vantage 400 Motor - Single Swing
The Centurion Vantage 500 Double Swing Gate Motor Kit is a comprehensive solution for automating double swing gates. This kit includes two powerful motors, control electronics, and all necessary accessories for installation. Designed for 240V operation, it provides reliable and efficient gate automation for double swing gates. With a maximum gate weight capacity of 750kg per leaf, this motor kit offers enhanced convenience and security. It features adjustable speed and force settings, ensuring smooth and safe gate operation. The Centurion Vantage 500 Double Swing Gate Motor Kit is a reliable choice for seamless automation of your double swing gates.
Max Weight : 750kg per leafMax Width of Gate/Door: 4m per leaf
1 Centsys Vantage 500 Motor - Double Swing
The Centurion Vantage 400 Double Swing Gate Motor Kit is a comprehensive solution for automating double swing gates. This kit includes two powerful motors, control electronics, and accessories necessary for installation. Designed for 240V operation, it provides reliable and smooth gate movement for gates weighing up to 500kg per leaf. The kit features adjustable speed and force settings, ensuring optimal performance and safety. With its robust construction and advanced features, the Centurion Vantage 400 Double Swing Gate Motor Kit offers convenience, security, and durability.
Max Weight : 500kg per leafMax Width of Gate/Door: 2.5m per leaf
1 Centsys Vantage 400 - Double Swing Gate Motor
Exceptionally easy system setup via LCD user interface.
Supports inward- and outward-opening gates without needing mechanical endstops.
High push force.
Full position control.
Fast operating speed, with smooth acceleration and deceleration.
Safe anti-crushing protection.
Multiple operating features including Intruder-detection Alarm Modes (a world first).
Onboard CENTSYS code-hopping multichannel receiver with selective add and delete.
Battery backup for uninterrupted operation during power failures
The BFT Virgo Smart BT A20 Single Swing Gate Motor Kit is a motor kit designed for single swing gates. It includes the Virgo Smart BT A20 motor, control board, mounting brackets, and other necessary components for efficient gate automation. The motor operates on a 240V power supply and is suitable for gates weighing up to 200 kg and with a maximum length of 2 meters. With smart technology integration, the motor can be easily controlled remotely using a smartphone app or integrated with other gate automation systems.
Max Weight : 200kgMax Width of Gate/Door: 2m
1 BFT Virgo Smart BT A20 240v w/ Single Swing
The BFT Virgo Smart BT A20 Double Swing Gate Motor Kit is a solar-powered motor kit designed for double swing gates. It includes all the necessary components for efficient and eco-friendly gate automation, including the Virgo Smart BT A20 solar motor, control board, solar panel, mounting brackets, and accessories. The motor is suitable for gates weighing up to 400 kg and with a maximum length of 2 meters per leaf. It features smart technology for easy integration with gate automation systems and can be controlled remotely via a smartphone app.
Max Weight : 200kg per leafMax Width of Gate/Door: 2m per leaf
1 BFT Virgo Smart BT A20 w/ Double Swing
1 Solar Panel
The BFT Virgo Smart BT A20 Double Swing Gate Motor Kit is a low-voltage motor kit designed for double swing gates. It includes all the necessary components for efficient and reliable operation, including the Virgo Smart BT A20 motor, control board, mounting brackets, and accessories. The motor is suitable for gates weighing up to 400 kg and with a maximum length of 2 meters per leaf. It features smart technology for easy integration with gate automation systems and can be controlled remotely via a smartphone app.
1 BFT Virgo Smart BT A20 low voltage w/ Double Swing
The MOT210 BFT Virgo Smart BT A20 Double Swing Gate Motor Kit is a high-quality solution for automating your double swing gate. This kit includes BFT Virgo Smart BT A20 motors that are designed for reliable and efficient performance. With their 240V power supply, these motors offer powerful operation and can handle various gate sizes and weights. The kit comes with all the necessary components for easy installation and includes user-friendly controls. With the BFT Virgo Smart BT A20 Double Swing Gate Motor Kit, you can enjoy convenient and secure automated access to your property.
1 BFT Virgo Smart BT A20 240v w/ Double Swing
BFT Solar Kit - Ecosol & Panel 20W
The ET810 BFT Solar Kit Ecosol Panel is a reliable and eco-friendly solution designed to power gate systems using solar energy. This solar kit includes the BFT Ecosol Panel, which harnesses solar power to provide a sustainable and renewable energy source for the gate system. By utilizing solar energy, the ET810 solar kit reduces reliance on traditional power sources, resulting in cost savings and environmental benefits. The BFT Ecosol Panel is designed to deliver efficient and consistent power to the gate system, ensuring reliable operation even in remote locations or areas with limited access to electricity. Upgrade your gate system with the ET810 BFT Solar Kit Ecosol Panel for sustainable and efficient power supply.
Kit includes:
BFT Genuine ECOSOL Solar Gate x1 BFT Solar Panel 10W x1
The MOT321 BFT Motor Single is a solar-powered swing gate kit designed for efficient and reliable gate automation. It features the BFT Kustos Ultra BT A25 motor, known for its high performance and durability. The solar power system ensures eco-friendly operation and eliminates the need for traditional power sources, making it suitable for remote locations or areas without electricity access. The motor offers smooth and quiet operation, enhancing convenience and user experience. The kit includes all necessary components for easy installation, allowing you to upgrade your swing gate with sustainable and hassle-free automation.
Max Weight : 400kgMax Width of Gate/Door: 2.5m
1 BFT Kustos Ultra A25
1 Control Board
